Facilities
Our Facilities
HEW Manufacturing Capacity
Lifting Facilities
BAY- 1
BAY- 2
Workshop Cranes Overview
EOT CRANE
Capacity: 65/15 MT
Span: 21.0 m
Lift: 12.5 m
EOT CRANE
Capacity: 35/10 MT
Span: 21.0 m
Lift: 12.5 m
EOT CRANE
Capacity: 15 MT
Span: 21.0 m
Lift: 12.5 m
EOT CRANE
Capacity: 10 MT
Span: 21.0 m
Lift: 12.5 m
HEW Growth Shop (HEW-GS)
(Operational Since Jan’2022)
Additional Facilities Available at HEW (08 Nos of Cranes)
BAY- A
BAY- B
BAY- C
BAY- D
Bay - A
Crane: EOT Crane 05 MT Capacity
Use: Machine Shop & Assembly
Qty: 1
Bay - B
Crane: EOT Crane 25/5 & 15 MT Capacity
Use: CNC Plasma Machine Installed / Assembly
Qty: 2
Bay - C
Crane: EOT Crane 25/10 & 15 MT Capacity
Use: Fabrication
Qty: 2
Bay - D
Crane: EOT Crane 35/10 MT (1 No) & 5 MT (2 Nos)
Use: Critical Fabrication – Segments Assembly / Equipment Storage
Qty: 3
HEW Manufacturing Capacity
EXISTING FACILITIES
Structural Machines
CNC Plasma Profile Cutting Machine, “Messer”
Capacity: Up to 200 mm thick x 18,500 mm long Bed
3-Roll Plate Bending Machine, “Thyssen-Wagner” / Germany
Capacity: Cold bending 90 mm thick plates x 3100 mm wide (max.)
4-Roll Plate Bending Machine, “C J Hosung” / Korea
Capacity: Cold bending 25 mm thick plates x 3000 mm wide (max.)
Machine Tools
CNC Horizontal Boring Machine, “JURAISTI” MP-7 / Spain (Floor Type)
Specs: Spindle Dia 180 mm, Traverse (X/Y/Z): 10600 x 3600 x 1700 mm
5-Axis CNC Horizontal Boring Machine, “JURAISTI” TX-1 / Spain (Table Type)
Specs: Travelling Column Milling Machine with rotary Table
Capacity: 50 MT, Traverse (X/Y/Z & W): 3800 x 1800 x 1120 & 450 mm
Spindle: Dia 125 mm
CNC Vertical Boring Machine, “UMARO” / Romania
Table Dia: 4000 mm
Capacity: Dia 5300 x 2700 mm Turning Height
Additional Machinery Installed & Operational at HEW & HEW GS
(In last 01 Year)
Machine Tools
CNC Horizontal Boring Machine “JURAISTI” TP-5 / Spain: Spindle Dia. 150 mm, Traverse (X/Y/Z): 5000 x 3500 x 2000 mm with Rotary table dia 2000mm
CNC HBM (SACEM Table Type): Spindle Dia. 125 mm, Traverse (X/Y/Z): 3500 x 2000 x 1600 mm
CNC VTL (Vertical Turning Lathe) – HMT / Model VT 510/2011: Chuck size 1500mm, Swing 2000 mm, Height 2000 mm, ATC – 12 Tools
CNC VMC (Vertical Machining Centre) – BFW / Model BMV 60: Traverse (X/Y/Z) 1050 × 610 × 610 mm with table 600 × 1250 mm
Structural / Fabrication Machines
CNC Lathe – HMT/SB 60/2010: Chuck size 600mm, Between Centre 2000 mm
CNC Plate Drilling Machine: Table Size 3000 × 2500 mm, Drilling Dia. 36 mm
CNC Flame Plasma Profile Cutting Machine “ESAB” / iSGM 350: Bed Size 3500 × 24,000 mm, Suitable for plates up to 3–150 mm thickness
Welding Machines: 12 Nos / 04 Nos EWS Germany make Welding Machines
